UltraLight Plywood
UltraHex Plywood
Pickup available at 2382 S Redwood Road
Usually ready in 1 hour
Shipping
Shipping options shown at checkout.
Ships on a pallet.
Ships within 24 hours, Monday through Thursday.
UltraHex sizes available in stock
6mm (1/4") x 48" x 96" (4' x8') sheet
12mm (1/2") x 48" x 96" (4' x 8') sheet
18mm (3/4") x 48" x 96" (4' x 8') sheet
Can be cut down upon request. Call for cut pricing 801-972-5211
Lose the weight
If you're manufacturing any product that ships then you are well aware of how that extra weight can equate to reduced profits. With UltraHex, the average weight savings is around 40% compared to similar high grade plywoods. In fact, a sheet of 3/4" weighs less than the average 1/2" baltic birch core hex ply.
UltraHex is a great substitute for all those Riga Heska (Hex Ply) projects. A smooth phenolic back with a scuff-resistant, high-wear, textured phenolic top surface, the new UltraHex has all the durability without the weight.
|
UltraHex (UltraLight core)
|
Riga Heska (Baltic birch core)
|
|
|---|---|---|
| 6mm (1/4") x 48" x 96" | ||
| 6mm (1/4") x 48" x 96" | 19 lbs | 26 lbs* |
| 12mm (1/2") x 48" x 96" | ||
| 12mm (1/2") x 48" x 96" | 37 lbs | 58 lbs* |
| 18mm (3/4") x 48" x 96" | ||
| 18mm (3/4") x 48" x 96" | 54 lbs | 88 lbs* |
* Baltic birch core hex weights can vary based on brand.
Easy to work with
- Breath-easy adhesive, low dust, low VOCs
- Consistent density & tight thickness tolerances, great for CNC work
- Minimum voids
- Exterior adhesive throughout for superior water resistance
- Less weight, less manpower required for handling
- Scuff and wear resistant Hex texture phenolic film front surface, smooth phenolic film backing
Specifications
The perfect plywood for high-wear areas. Tested and certified to meet or exceed industry standards.
- Environmentally friendly
- Durable
- Hygienic
- Odorless
- Easy to clean
- Waterproof
- Resists commonly used chemicals
SIZE / WEIGHT
- 6mm (1/4") - 20 lbs (3.07 kg/m²)
- 12mm (1/2") - 37 lbs (5.64 kg/m²)
- 18mm (3/4") - 54 lbs (8.23 kg/m²)
LAY UP
- 6mm (1/4") ...5 ply
- 12mm (1/2")...9 ply
- 18mm (3/4")...13 ply
Front face = Hex texture phenolic film
Back face - Smooth phenolic film
Calibrated +/- 0.3mm
ADHESIVE
Breathe Free exterior grade adhesive = CARB2, TSCA Title VI 3rd party certified
BIFMA TESTING
X5.5-08-04.3 (Stability Test) - PASS
X5.5-08-05.2 (Strength Test) - PASS
X5.5-08-06.0 (Top Load Test) - PASS
X5.5-08-05.4 (Strength Test) - PASS
X5.5-08-05.3 (Strength Test) - PASS
X5.5-08-08.0 (Leg Strength Test) - PASS
X5.5-08-05.5 (Strength Test) - PASS
SUSTAINABLE GROWTH
Sustainable, Eco-Friendly, Farm Grown source
ITTO Objective 200 - Pass
ISO 14000 - Certified
LACEY ACT - Compliant
MSDF
Material Safety Data Sheet PDF download
CNC RECOMMENDATIONS
For best CNC results, we recommend the following:
For Edge Cuts, cutting a shape from a sheet, we suggest no larger than a .25” COMPRESSION END MILL set to:
- 18000 r.p.m. Spindle speed
- 450 inches/min Feed Rate
- 70 inches/min Plunge Rate
For Pocket Cuts, cutting a recess into a sheet, we use a .25” DOWN-CUT END MILL set to:
- 18000 r.p.m. Spindle speed
- 300 inches/min Feed Rate
- 47 inches/min Plunge rate
The type of CNC and the quality of the End Mills vary, so we suggest testing first for best results before any production.
