UltraLight sizes available in stock
6mm (1/4") x 48" x 96" (4' x 8') sheet*
12mm (1/2") x 48" x 96" (4' x 8') sheet*
18mm (3/4") x 48" x 96" (4' x 8') sheet*
Can be cut down upon request. Call for cut pricing 801-972-5211
Lose the weight
If you're manufacturing any product that ships then you are well aware of how that extra weight can equate to reduced profits. With UltraLight, the average weight savings is around 40% compared to similar high grade plywoods. In fact, a sheet of 3/4 inch UltraLight weighs less than 1/2 inch of baltic birch! Lose the weight, save on freight.
UltraLight is also also a great choice of material for products used in transportation. Work trailers, camper vans, buses, and RVs can all benefits from weight reduction when it comes to reduced fuel and machine wear costs.
|
UltraLight Plywood
|
Baltic Birch Plywood
|
|
|---|---|---|
| 6mm (1/4") x 48" x 96" | ||
| 6mm (1/4") x 48" x 96" | 20 lbs | 25 lbs* |
| 12mm (1/2") x 48" x 96" | ||
| 12mm (1/2") x 48" x 96" | 31 lbs | 50 lbs* |
| 18mm (3/4") x 48" x 96" | ||
| 18mm (3/4") x 48" x 96" | 51 lbs | 75 lbs* |
* Baltic birch plywood weights can vary based on brand.
Easy to work with
- Breath-easy adhesive, low dust, low VOCs
- Consistent density & tight thickness tolerances, great for CNC work
- Minimum voids & no footballs, no fillers required
- Exterior adhesive throughout for superior water resistance
- AA grade 200 grit sanded for reduced prep time
- Less weight, less manpower required for handling
Specifications
For best CNC results, we recommend the following:
For Edge Cuts, cutting a shape from a sheet, we use a .375” COMPRESSION END MILL set to:
- 18000 r.p.m. Spindle speed
- 450 inches/min Feed Rate
- 70 inches/min Plunge Rate
For Pocket Cuts, cutting a recess into a sheet, we use a .25” DOWN-CUT END MILL set to:
- 18000 r.p.m. Spindle speed
- 300 inches/min Feed Rate
- 47 inches/min Plunge rate
The type of CNC and the quality of the End Mills vary, so we suggest testing first for best results before any production.
SIZE / WEIGHT
- 6mm (1/4") - 20 lbs (3.07 kg/m²)
- 12mm (1/2") - 31 lbs (4.72 kg/m²)
- 18mm (3/4") - 51 lbs (7.78 kg/m²)
LAY UP
- 6mm (1/4") ...5 ply
- 12mm (1/2")...9 ply
- 18mm (3/4")...13 ply
GRADE / ADHESIVE
Engineered for real world applications. Breath-free exterior adhesive, strong, odorless moisture resistant, and eco-friendly. Tested and certified to meet or exceed industry standards.
Breathe-free exterior adhesive = CARB2, TSCA Title VI 3rd party certified
Front & back veneer = AA Grade
220 grit super-sanded both sides
Calibrated +/- 0.3mm
BIFMA TESTING
X5.5-08-04.3 (Stability Test) - PASS
X5.5-08-05.2 (Strength Test) - PASS
X5.5-08-06.0 (Top Load Test) - PASS
X5.5-08-05.4 (Strength Test) - PASS
X5.5-08-05.3 (Strength Test) - PASS
X5.5-08-08.0 (Leg Strength Test) - PASS
X5.5-08-05.5 (Strength Test) - PASS
SUSTAINABLE GROWTH
Sustainable, Eco-Friendly, Farm Grown source
ITTO Objective 200 - Pass
ISO 14000 - Certified
LACEY ACT - Compliant
MSDF
Material Safety Data Sheet PDF download
